| Model | UST-300 Block | UST-300 | UST-600 | UST-900 | UST-1200 | UST-1800 | UST-2400 |
|---|---|---|---|---|---|---|---|
| Solar Panel | 1 × 435W | 1 × 435W | 2 × 435W | 3 × 435W | 4 × 435W | 6 × 435W | 8 × 435W |
| Panel Lifting | 0°~90° Manual Lifting | 10°~45° Manual Lifting | 10°~45° Manual Lifting | 30°~38° Electric Lifting | 30°~38° Electric Lifting | 0°~25° Hydraulic Lifting | 0°~25° Hydraulic Lifting |
| GEL/LFP Battery | 1 × 200Ah DC12.8V | 2 × 200Ah DC12V | 4 × 200Ah DC12V | 6 × 200Ah DC12V | 8 × 200Ah DC12V | 12 × 200Ah DC12V | 16 × 200Ah DC12V |
| Battery Capacity | 2560Wh 80% Deep | 4800Wh 80% Deep | 9600Wh 80% Deep | 14400Wh 80% Deep | 19200Wh 80% Deep | 28800Wh 80% Deep | 38400Wh 80% Deep |
| System Voltage | DC12V | DC12V | DC24V | DC24V | DC48V | DC48V | DC48V |
| Rotation | No | Optional | Optional | 350° Electric | 350° Electric | 350° Electric | 350° Electric |
| Tilt | No | 90° Electric | 90° Electric | 90° Electric | 90° Electric | 90° Electric | 90° Electric |
| Controller | 40A MPPT | 40A MPPT | 40A MPPT | 60A MPPT | 40A MPPT | 60A MPPT | 80A MPPT |
| Mast | 5M 4 Sections | 7M 5 Sections | 7M 5 Sections | 9M 5 Sections | 9M 5 Sections | 9M 9 Sections | 9M 9 Sections |
| Mast Lifting | Manual Winch | Manual Winch | Manual Winch | Electric Winch | Electric Winch | Hydraulic | Hydraulic |
| Trailer Standard | No | US / AU / EU | US / AU / EU | US / AU / EU | US / AU / EU | US / AU / EU | US / AU / EU |
| Hitch | No | 2'' Ball / 3'' Ring | 2'' Ball / 3'' Ring | 2'' Ball / 3'' Ring | 2'' Ball / 3'' Ring | 2'' Ball / 3'' Ring | 2'' Ball / 3'' Ring |
| Brake | No | No | Electric | Mechanical | Mechanical | Electric | Electric |
| Axle | No | Single | Single | Single | Single | Double | Double |
| Tire | No | 14 inch | 14 inch | 15 inch | 15 inch | 15 inch | 15 inch |
| Outriggers | No | 4 × | 4 × | 4 × | 4 × | 4 × | 4 × |
| Forklift Holes | 4 × | 2 × | 2 × | 2 × | 2 × | 2 × | 2 × |
| Working Temp | 0°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C |
| Charging Time | 4.4 hours | 9.3 hours | 9.3 hours | 9.3 hours | 9.3 hours | 9.3 hours | 9.3 hours |
| Running Time | 9.6 hours | 19.2 hours | 19.2 hours | 19.2 hours | 19.2 hours | 19.2 hours | 19.2 hours |
| Dimension (mm) | 1000*1000*2900 | 2500*2150*2700 | 3700*2150*2750 | 3550*1650*2800 | 3650*2250*2800 | 4150*2250*2800 | 4150*2250*2800 |
| Weight | 450kg | 750kg | 950kg | 1400kg | 1600kg | 2000kg | 2400kg |
| QTY in 20' / 40' | 10 units / 20 units | 8 units / 16 units | 8 units / 16 units | 3 units / 7 units | 2 units / 4 units | 2 units / 4 units | 2 units / 4 units |
